metadata

license: mit
license_link: https://huggingface.co/microsoft/phi-4/resolve/main/LICENSE
language:
  - en
pipeline_tag: text-generation
base_model: microsoft/phi-4
tags:
  - phi
  - nlp
  - math
  - code
  - chat
  - conversational
  - neuralmagic
  - redhat
  - llmcompressor
  - quantized
  - int8

phi-4-quantized.w8a8

Model Overview

Model Architecture: Phi3ForCausalLM
- Input: Text
- Output: Text
Model Optimizations:
- Activation quantization: INT8
- Weight quantization: INT8
Intended Use Cases: This model is designed to accelerate research on language models, for use as a building block for generative AI powered features. It provides uses for general purpose AI systems and applications (primarily in English) which require:
1. Memory/compute constrained environments.
2. Latency bound scenarios.
3. Reasoning and logic.
Out-of-scope: This model is not specifically designed or evaluated for all downstream purposes, thus:
1. Developers should consider common limitations of language models as they select use cases, and evaluate and mitigate for accuracy, safety, and fairness before using within a specific downstream use case, particularly for high-risk scenarios.
2. Developers should be aware of and adhere to applicable laws or regulations (including privacy, trade compliance laws, etc.) that are relevant to their use case, including the model’s focus on English.
3. Nothing contained in this Model Card should be interpreted as or deemed a restriction or modification to the license the model is released under.
Release Date: 03/03/2025
Version: 1.0
Model Developers: Red Hat (Neural Magic)

Model Optimizations

This model was obtained by quantizing activations and weights of phi-4 to INT8 data type. This optimization reduces the number of bits used to represent weights and activations from 16 to 8, reducing GPU memory requirements (by approximately 50%) and increasing matrix-multiply compute throughput (by approximately 2x). Weight quantization also reduces disk size requirements by approximately 50%.

Only weights and activations of the linear operators within transformers blocks are quantized. Weights are quantized with a symmetric static per-channel scheme, whereas activations are quantized with a symmetric dynamic per-token scheme. A combination of the SmoothQuant and GPTQ algorithms is applied for quantization, as implemented in the llm-compressor library.

Deployment

This model can be deployed efficiently using the vLLM backend, as shown in the example below.

from vllm import LLM, SamplingParams
from transformers import AutoTokenizer

model_id = "neuralmagic-ent/phi-4-quantized.w8a8"
number_gpus = 1

sampling_params = SamplingParams(temperature=0.7, top_p=0.8, max_tokens=256)

tokenizer = AutoTokenizer.from_pretrained(model_id)

messages = [
    {"role": "user", "content": "Give me a short introduction to large language model."},
]

prompts = tokenizer.apply_chat_template(messages, tokenize=False)

llm = LLM(model=model_id, tensor_parallel_size=number_gpus)

outputs = llm.generate(prompts, sampling_params)

generated_text = outputs[0].outputs[0].text
print(generated_text)

vLLM aslo supports OpenAI-compatible serving. See the documentation for more details.

Deploy on Red Hat AI Inference Server

$ podman run --rm -it --device nvidia.com/gpu=all -p 8000:8000 \
 --ipc=host \
--env "HUGGING_FACE_HUB_TOKEN=$HF_TOKEN" \
--env "HF_HUB_OFFLINE=0" -v ~/.cache/vllm:/home/vllm/.cache \
--name=vllm \
registry.access.redhat.com/rhaiis/rh-vllm-cuda \
vllm serve \
--tensor-parallel-size 8 \
--max-model-len 32768  \
--enforce-eager --model RedHatAI/phi-4-quantized.w8a8

See Red Hat AI Inference Server documentation for more details.

Deploy on Red Hat Enterprise Linux AI

# Download model from Red Hat Registry via docker
# Note: This downloads the model to ~/.cache/instructlab/models unless --model-dir is specified.
ilab model download --repository docker://registry.redhat.io/rhelai1/phi-4-quantized-w8a8:1.5

# Serve model via ilab
ilab model serve --model-path ~/.cache/instructlab/models/phi-4-quantized-w8a8

# Chat with model
ilab model chat --model ~/.cache/instructlab/models/phi-4-quantized-w8a8

See Red Hat Enterprise Linux AI documentation for more details.

Deploy on Red Hat Openshift AI

# Setting up vllm server with ServingRuntime
# Save as: vllm-servingruntime.yaml
apiVersion: serving.kserve.io/v1alpha1
kind: ServingRuntime
metadata:
 name: vllm-cuda-runtime # OPTIONAL CHANGE: set a unique name
 annotations:
   openshift.io/display-name: vLLM NVIDIA GPU ServingRuntime for KServe
   opendatahub.io/recommended-accelerators: '["nvidia.com/gpu"]'
 labels:
   opendatahub.io/dashboard: 'true'
spec:
 annotations:
   prometheus.io/port: '8080'
   prometheus.io/path: '/metrics'
 multiModel: false
 supportedModelFormats:
   - autoSelect: true
     name: vLLM
 containers:
   - name: kserve-container
     image: quay.io/modh/vllm:rhoai-2.20-cuda # CHANGE if needed. If AMD: quay.io/modh/vllm:rhoai-2.20-rocm
     command:
       - python
       - -m
       - vllm.entrypoints.openai.api_server
     args:
       - "--port=8080"
       - "--model=/mnt/models"
       - "--served-model-name={{.Name}}"
     env:
       - name: HF_HOME
         value: /tmp/hf_home
     ports:
       - containerPort: 8080
         protocol: TCP

# Attach model to vllm server. This is an NVIDIA template
# Save as: inferenceservice.yaml
apiVersion: serving.kserve.io/v1beta1
kind: InferenceService
metadata:
  annotations:
    openshift.io/display-name: phi-4-quantized.w8a8 # OPTIONAL CHANGE
    serving.kserve.io/deploymentMode: RawDeployment
  name: phi-4-quantized.w8a8        # specify model name. This value will be used to invoke the model in the payload
  labels:
    opendatahub.io/dashboard: 'true'
spec:
  predictor:
    maxReplicas: 1
    minReplicas: 1
    model:
      modelFormat:
        name: vLLM
      name: ''
      resources:
        limits:
          cpu: '2'			# this is model specific
          memory: 8Gi		# this is model specific
          nvidia.com/gpu: '1'	# this is accelerator specific
        requests:			# same comment for this block
          cpu: '1'
          memory: 4Gi
          nvidia.com/gpu: '1'
      runtime: vllm-cuda-runtime	# must match the ServingRuntime name above
      storageUri: oci://registry.redhat.io/rhelai1/modelcar-phi-4-quantized-w8a8:1.5
    tolerations:
    - effect: NoSchedule
      key: nvidia.com/gpu
      operator: Exists

# make sure first to be in the project where you want to deploy the model
# oc project <project-name>
# apply both resources to run model
# Apply the ServingRuntime
oc apply -f vllm-servingruntime.yaml
# Apply the InferenceService
oc apply -f qwen-inferenceservice.yaml

# Replace <inference-service-name> and <cluster-ingress-domain> below:
# - Run `oc get inferenceservice` to find your URL if unsure.
# Call the server using curl:
curl https://<inference-service-name>-predictor-default.<domain>/v1/chat/completions
        -H "Content-Type: application/json" \
        -d '{
    "model": "phi-4-quantized.w8a8",
    "stream": true,
    "stream_options": {
        "include_usage": true
    },
    "max_tokens": 1,
    "messages": [
        {
            "role": "user",
            "content": "How can a bee fly when its wings are so small?"
        }
    ]
}'

See Red Hat Openshift AI documentation for more details.

Creation

Creation details

This model was created with [llm-compressor](https://github.com/vllm-project/llm-compressor) by running the code snippet below.

from transformers import AutoModelForCausalLM, AutoTokenizer
from llmcompressor.modifiers.quantization import GPTQModifier
from llmcompressor.modifiers.smoothquant import SmoothQuantModifier
from llmcompressor.transformers import oneshot
from datasets import load_dataset

# Load model
model_stub = "microsoft/phi-4"
model_name = model_stub.split("/")[-1]

num_samples = 1024
max_seq_len = 8192

tokenizer = AutoTokenizer.from_pretrained(model_stub)

model = AutoModelForCausalLM.from_pretrained(
    model_stub,
    device_map="auto",
    torch_dtype="auto",
)

def preprocess_fn(example):
  return {"text": tokenizer.apply_chat_template(example["messages"], add_generation_prompt=False, tokenize=False)}

ds = load_dataset("neuralmagic/LLM_compression_calibration", split="train")
ds = ds.map(preprocess_fn)

# Configure the quantization algorithm and scheme
recipe = [
    SmoothQuantModifier(
        smoothing_strength=0.7,
        mappings=[
            [["re:.*qkv_proj"], "re:.*input_layernorm"],
            [["re:.*gate_up_proj"], "re:.*post_attention_layernorm"],
        ],
    ),
    GPTQModifier(
        ignore=["lm_head"],
        sequential_targets=["Phi3DecoderLayer"],
        dampening_frac=0.01,
        targets="Linear",
        scheme="W8A8",
    ),
]

# Apply quantization
oneshot(
    model=model,
    dataset=ds,
    recipe=recipe,
    max_seq_length=max_seq_len,
    num_calibration_samples=num_samples,
)

# Save to disk in compressed-tensors format
save_path = model_name + "-quantized.w8a8"
model.save_pretrained(save_path)
tokenizer.save_pretrained(save_path)
print(f"Model and tokenizer saved to: {save_path}")

Evaluation

The model was evaluated on the OpenLLM leaderboard tasks (version 1) with the lm-evaluation-harness and the vLLM engine, using the following command:

lm_eval \
  --model vllm \
  --model_args pretrained="neuralmagic-ent/phi-4-quantized.w8a8",dtype=auto,gpu_memory_utilization=0.6,max_model_len=4096,enable_chunk_prefill=True,tensor_parallel_size=1 \
  --tasks openllm \
  --batch_size auto

Accuracy

Open LLM Leaderboard evaluation scores

Benchmark	phi-4	phi-4-quantized.w8a8 (this model)	Recovery
MMLU (5-shot)	80.30	80.39	100.1%
ARC Challenge (25-shot)	64.42	64.33	99.9%
GSM-8K (5-shot, strict-match)	90.07	90.30	100.3%
Hellaswag (10-shot)	84.37	84.30	99.9%
Winogrande (5-shot)	80.58	79.95	99.2%
TruthfulQA (0-shot, mc2)	59.37	58.82	99.1%
Average	76.52	76.35	99.8%
